Photovoltaic Micro-station Energy Cabinet

The Huijue Photovoltaic Micro-station Energy Cabinet is a compact, intelligent energy solution for remote communications applications, microgrids, and off-grid applications. Combining solar, wind, and grid inputs with advanced energy storage and monitoring, the cabinet provides reliable, renewable power in extreme environments.

Key Features

• Integrated Renewable Energy: Dual 450Wp photovoltaic modules (900Wp total) and wind power inputs of 300W to 1000W are supported, allowing hybrid energy production.
• Genuine Energy Storage: With a 5kWh lithium iron phosphate battery (100Ah, 51.2V) as genuine backup power.
• Modular Design: Tower or wall mountings with minimal footprint (400mm W × 500mm D × 700mm H) and IP55-rated enclosure for durability.
• Sophisticated Power Management: Featuring a 2U embedded hybrid power system offering DC48V output, combined with intelligent circuit breakers, ODF module, and FSU monitoring.
• Comprehensive Monitoring: Provides RS485 communication, temperature and humidity sensing, smoke sensing, access control, and water immersion sensing, with a maximum of 1000 alarm history records.
• Robust Environmental Resilience: Has operating temperatures of -20°C to +75°C (initial start-up at -40°C), humidity of 5%–95% (non-condensing), and altitudes of up to 4000m.

Applications

Suitable for telecom base stations, smart traffic control systems, industrial applications, and remote locations requiring stand-alone, renewable power supplies.
