1. Product Overview

Huijue Group Armored Fiber Cable Connector is designed for reliable optical connectivity in demanding communication environments. The cable features tight-buffered optical fibers protected by a stainless-steel tube, reinforced with wire braiding and covered by a flame-retardant outer jacket.

This multilayer construction provides enhanced mechanical protection, including resistance to compression, tensile stress, and rodent damage. Despite its protective structure, the cable maintains a compact diameter and flexible handling characteristics, making it suitable for fiber optic patch cords, pigtails, and other optical connectivity assemblies.

Huijue Group offers customizable fiber types, cable lengths, diameters, and connector configurations to meet different network installation requirements.

2. Key Features

• Robust Armored Structure: Stainless-steel tubing and wire braiding provide additional mechanical protection for optical fibers.
• High Compression Resistance: Helps protect fibers against external pressure and mechanical damage.
• Rodent Resistance: The metal protective layer helps reduce the risk of damage caused by rodents.
• High Tensile Strength: Designed to withstand pulling forces encountered during cable routing and installation.
• Flame-Retardant Jacket: Supports indoor installations where suitable flame-retardant cable materials are required.
• Compact and Flexible: Combines mechanical protection with a relatively small cable diameter for convenient routing.
• Temperature Stability: Designed to maintain performance under varying temperature conditions.
• Customizable Connectors: Supports FC, SC, LC, ST, and other connector types according to project requirements.

3. Product Description

Enhanced Protection for Optical Fiber

Conventional fiber optic cables can be vulnerable to crushing, abrasion, and rodent damage in demanding installation environments. Armored fiber cables incorporate a metal protective layer around the optical fibers to improve mechanical durability.

Huijue Group armored fiber cable uses tight-buffered optical fibers within a stainless-steel tube, followed by wire-braided reinforcement and a flame-retardant outer jacket. This construction provides multiple layers of protection while retaining the flexibility needed for practical cable installation.

Flexible Connectivity for Communication Systems

The compact structure makes armored fiber cable suitable for applications where mechanical protection and efficient cable routing are both important. When terminated with compatible optical connectors, it can be used as an armored fiber patch cord for connections between communication equipment and optical distribution systems.

Available configurations include single-mode and multimode fibers, with different cable diameters and termination options to accommodate a range of equipment interfaces.

Customizable Fiber and Connector Configurations

Different applications require different optical and mechanical specifications. Huijue Group supports customization of fiber type, fiber count, cable length, cable diameter, connector interface, and connector end-face polishing.

Single-mode options include G.652 and G.657B fibers, while multimode configurations include 50/125 μm and 62.5/125 μm fibers. Connector options include FC, SC, LC, and ST, with PC, UPC, and APC polishing available where compatible.

4. Applications

• Telecommunications Equipment: Protected optical connections between communication devices and distribution systems.
• Industrial Environments: Fiber connections in areas where cables may be exposed to mechanical stress.
• Data Centers: Armored patch cords for equipment connections requiring additional physical protection.
• Fiber Distribution Systems: Connections between optical distribution frames, panels, and communication equipment.
• Outdoor Communication Equipment: Protected fiber connections in suitable outdoor enclosures and installations.
• Rodent-Prone Areas: Optical connectivity in locations where additional protection against rodent damage is needed.

5. Technical Specifications

Note: Final mechanical performance, temperature range, flame-retardant rating, and optical specifications depend on the selected cable construction and connector configuration. Confirm the required values against the applicable product datasheet before ordering.

6. Customization and Supply

Huijue Group provides armored fiber cable solutions for telecommunications operators, network contractors, industrial communication projects, equipment manufacturers, and fiber optic distributors.

Available customization options include:

• Single-mode or multimode fiber
• Fiber count and cable length
• 2.0 mm or 3.0 mm cable diameter options
• FC, SC, LC, ST, and other compatible connectors
• PC, UPC, or APC polishing
• Single-ended or dual-ended termination
• Customized packaging and labeling

For project inquiries, please provide the required fiber type, cable length, connector combination, installation environment, and mechanical protection requirements.

Contact Huijue Group to discuss your armored fiber cable requirements and customized optical connectivity solutions.
